LT-858-CC DMX to PWM Decoder
LT-858-CC
LT-858-CC with the standard RDM remote device management protocol, supports DMX512 signal bi-directional communication, achieves remote management of reading and writing DMX address (DMX master controller must recognize the RDM protocol). Realize 0-100% dimming or different lighting effects; work with DIM, CT, RGB,RGBW LED lamps.
Download Our Data Sheet
Precision LED control. Flexible current settings. Creative lighting possibilities.
Take your lighting installation to the next level with the LTECH LT-858-CC, a professional four-channel DMX/RDM constant-current decoder designed for precise control of LED lighting.
Combining adjustable output current, smooth 0–100% dimming, built-in lighting effects and convenient RDM remote management, the LT-858-CC gives lighting professionals greater flexibility when designing and configuring their installations.
From architectural lighting to colour-changing RGBW effects, enjoy precise control with a decoder built to adapt to your project.
Why you'll love the LT-858-CC
Adjustable Output Current
One decoder, multiple current settings.
Choose from 16 output-current settings ranging from 300mA to 1050mA using the onboard DIP switches.
This flexibility helps you configure the decoder to match the requirements of compatible constant-current LED modules.
Smooth 0-100% Dimming
Take your lighting from subtle ambient illumination to full brightness with a 0–100% dimming range.
Each of the four output channels can be controlled through the DMX system, giving you flexibility over brightness and colour effects.
DMX512 & RDM Support
Integrate the LT-858-CC into a compatible professional lighting control system using DMX512.
With RDM support, a compatible RDM master controller can communicate with the decoder in both directions and remotely read or write its DMX address.
Four-Channel Versatility
The LT-858-CC supports four output channels and is designed for use with DIM, CT, RGB and RGBW LED lighting.
Whether you're working with single-colour dimming, colour-temperature control or multicolour lighting, the four-channel architecture provides a flexible foundation for your installation.
Built-in Lighting Effects
Need to test your setup or explore lighting effects?
Switch to self-testing mode to access a selection of preset outputs.
Designed For Professional Installations
With a compact enclosure, RJ45 DMX/RDM connections and built-in configuration switches, the LT-858-CC is designed to integrate into professional lighting systems.
Its operating temperature range of -30°C to 65°C offers flexibility across a range of installation environments.
Flexible configuration, right at your fingertips
- Current Setting - Choose the appropriate output current from 300mA to 1050mA. Set the current with the power switched off.
- DMX Address - Set the initial DMX address using DIP switches 1–9 when operating in DMX mode.
- Operating Mode - Choose between RDM mode, DMX mode and self-testing mode according to your installation requirements.
- Self-testing - Activate the built-in test mode to select static colours or colour-changing effects.
TECHNICAL INFORMATION
Ready to take control?
Give your DMX lighting system the precision, flexibility and feedback it deserves.
LT-858-CC — professional DMX/RDM control in a compact package.
Add to your project today and bring your LED installation to life.
