MADRIX STELLA
MADRIX STELLA
The MADRIX STELLA is a dedicated control interface for DMX512 and Art-Net or Streaming ACN that is designed for high quality and practicability in permanent LED installations.
Package Contents:
- 1x MADRIX STELLA
- 1x Set of pluggable screw terminals (2x 3-pin and 1x 2-pin)
- 1x USB 2.0 cable (certified)
- 2x Wall-mount brackets
- 1x Technical manual / quick start guide
Download Our Data Sheet
Flexible network-based DMX distribution and RDM management for professional lighting systems.
MADRIX STELLA is a compact two-port network node that converts Art-Net or Streaming ACN (sACN) data to DMX512. Its two DMX ports can be configured automatically as inputs and/or outputs, providing two 512-channel DMX universes per device.
Designed for professional lighting installations, STELLA supports RDM over Art-Net, allowing compatible RDM devices to be discovered and managed. It also supports synchronised Art-Net output, HTP merging from two Ethernet sources, and linear daisy-chaining through its two Ethernet ports.
The device connects to compatible third-party lighting controllers or MADRIX 5 over USB. Its non-conductive enclosure supports standard 35 mm DIN-rail mounting, with additional brackets included for optional wall mounting.
Product Information
STELLA provides two DMX ports, each supporting 512 channels. Ports are automatically set as input and/or output according to the device configuration.
Convert Art-Net or Streaming ACN (sACN / ANSI E1.31) data to DMX512 for networked lighting applications.
STELLA supports RDM communication over Art-Net, including ArtRdm, required packets and continued discovery of RDM devices. It can act as an Art-Net node and RDM controller.
When used with MADRIX RADAR, connected RDM devices and sub-devices are automatically unlocked in the software as described by the manufacturer. RADAR provides access to the stated ANSI E1.20 and ANSI E1.37-1 RDM specifications over Art-Net.
Two Ethernet ports support separate network connections or linear daisy-chaining of multiple devices to simplify cable routing.
MADRIX 5 and MADRIX hardware support synchronisation of Art-Net data across output ports and multiple devices for coordinated lighting visuals.
The non-conductive enclosure is designed for 35 mm DIN rails. Two wall-mount brackets are included for optional wall installation.
STELLA 8
MADRIX STELLA 8 combines incredible features for DMX512 and RDM into a single DIN-rail controller that easily copes with high bandwidths in data-intensive lighting-control networks.
Take control like never before!
Reliable Network-Based DMX and RDM with MADRIX STELLA
MADRIX STELLA combines two configurable DMX ports, Art-Net and sACN networking, and RDM support in a compact installation-friendly device. It is a practical choice for lighting systems that require flexible DMX distribution and network-based RDM device management.
